| product description | GYFTY53 loose tube stranding non-metal strength member flooding jelly compound PE inner jacket steel-polyethylene adhesive outer jacket |
| standards | YD/T 901-2009 outdoor layer stranded optical cable for telecommunications |
| applications | buried |
| characteristics | excellent lateral pressure resistance, mechanical and temperature performance nice water-blocking performance strict manufacturing processes loose tube material has good hydrolysis resistance performance and high strength |
| note | other types of fiber can be provided according to customer's demands |
| fiber | structure | long-term/short-term permitted tensile (N) | long-term/short-term permitted crush(N) | static /dynamic bend radius(mm) |
| 2-36 | 1+6 | 1000/3000 | 1000/3000 | 12.5D/25D |
| 38-72 | 1+6 | 1000/3000 | 1000/3000 | 12.5D/25D |
| 74-84 | 1+7 | 1000/3000 | 1000/3000 | 12.5D/25D |
| 86-96 | 1+8 | 1000/3000 | 1000/3000 | 12.5D/25D |
| 98-108 | 1+9 | 1000/3000 | 1000/3000 | 12.5D/25D |
| 110-120 | 1+10 | 1000/3000 | 1000/3000 | 12.5D/25D |
| 122-132 | 1+11 | 1000/3000 | 1000/3000 | 12.5D/25D |
| 134-144 | 1+12 | 1000/3000 | 1000/3000 | 12.5D/25D |
| 146-216 | 1+6+12 | 1000/3000 | 1000/3000 | 12.5D/25D |
| 218-288 | 1+9+15 | 1000/3000 | 1000/3000 | 12.5D/25D |
cable structure
finished cable
transmission performance
| item | 62.5µm (OM1) 850nm/1300nm | 50µm (OM2) 850nm/1300nm | G.652 1310nm/1550nm | G.655 1550nm/1625nm |
| attenuation of max value (dB/km) | 3.5/1.5 | 3.5/1.5 | 0.36/0.22 | 0.22/0.26 |
| attenuation of typical value (dB/km) | 3.5/1.5 | 3.0/1.0 | 0.35/0.21 | 0.21/0.24 |
Hongan Group Co., Ltd, which locates at Wendeng District, Weihai City , Shandong Province of China, was eatablished in 1985.It has 1500 empolyees and total assets is over 1.5 billion RMB. It covers an area of 2 million square meters,construction area is 0.6 million square meters, main products form a big whole industry chain, and can be devided into 9 categories:
1.optical fiber
2.indoor & outdoor optical fiber cable (armored & nonarmored cable , drop cable etc)
3.CAT5 CAT5E CAT6 CAT7 network lan cable (both UTP and FTP)
4.municipal telephone cable
5.patchcord, fiber jumper
6.fiber pigtail
7.EPON,GPON , data center solutions and equipments
8.FTTH products
9.OEM products, customized new cable
Main product model
outdoor layer stranded optical cable
GYTA,GYTS,GYTA53,GYTY,GYTY53,GYTZA,GYTZS,GYTZA53,GYTA5333,GYTA33,GYTA333,GYFTY,GYFTA,GYFTS,GYXS,GYFXY,GYFTY53,GYFTA53,GYFY,GYFTY73,ADSS,GYTC8A,GYTC8S,GYTC8Y,GYFC8Y,GYXC8Y,GCYFY
outdoor central tube optical cable
GYXTW,GYXTW53,GYXTS
ribbon cable
GYDTA,GYDTS,GYDXTW
drop cable
GJFJV,GJFJH,GJXH,GJXV,GJXFH,GJXFV,GJYXCH,GJYXFCH,GJXDH,GJYXDCH,as well as twin cable
indoor optical cable
GJFJBV,GJPFJH,GJPFJV,GJBFJV
data cable
indoor & outdoor CAT5E, indoor & outdoor CAT6, HSYV3 25& 50& 100 pairs, HSYV5 25& 50&100 pairs
municiple telephone cable
HYA,HYA53,HYAT,HYAC,HYAT53,HYV
optic-electric composite cable
GDTA,GDTS
distribution cabling system
RJ-45 panel, 110 patch panel, CAT5E & CAT6 various patch panel, patchcord& pigtail, fiber optic coupler, optical distribution frame, fiber optic cable connector box, optical fiber terminal box, OLT, ONU, network module, PLC splitter, FTTH splitters distribution box, optical cable cross connecting cabinet, fiber closure, PCI-E server adaptor, etc
yearly productive capacity
fiber 4 million core fkm
fiber cable 1.2 million core km
data cable 96000 cases
municiple telephone cable 6 couple million 6 couple km
annual export volume
200,000 km cable
8 advantages:
1.top-class equipments imported from the US, Japan and EU
2.advanced technical arts
3.innovation team
4.modern management
5.high quality staff
6.CE,UL,ROHS,CCC,ISO9001 certicication
7.postdoctoral scientific research workstation
8.provincial garden-style enterprise
Hongan practices the scientific outlook on development, and insists the philosophy of specialization and high-tech in operation and development.It owned excellent performance and honors :
China's TOP 100 Electrical Machinery and Equipment Manufacturing Enterprises
China's Electrical Information BEST 100 enterprises
National Torch Plan high-tech enterprises
Shandong TOP 10 high-tech enterprises
Shandong BEST 100 industrial enterprises etc
China's AAA level credit enterprise
Shandong provincial famous trademark
strategies:
1.technical innovation
2.talent development
3.culture fostering
our responsibility
1.popularize Chinese culture
2.innovate Chinese brand
3.promote Chinese technology
4.lead industry progress
5.world-famous enterprise
6.feedback employees and society
Corporate culture
company vision-----------become a world's leader in cable and optical communications accessories industry
company mission---------optical fiber brings a better life
company values----------credibility first , quality first , innovation first
service concept------------think for you
main reference of key performance
1.exports area: Combodia , Vietnam, Myanmar, Laos, Bahrain, United Arab Emirates, Saudi Arabia, Brazil, Cameroon, Iraq, South Africa, Nicaragua, Costa Rica
2.Trunk Line Communication Network in Vietnam, Myanmar and Cambodia
3.village to village projects in Laos
4.integrated wiring projects in Bahrain, United Arab Emirates, Saudi Arabia, Brazil and the US
5.Backbone cabling projects of China Unicom , China Telecom in many provinces
6.nominated for 9 provincial radio and television projects, such as Shandong, Fujian, Hebei, Heilongjiang
7.subway projects of Shanghai , Qingdao and other cities
8.projects for Jinan Military , Nanjing Airforce and Engineering Command of PLA
9.Broadband access integrated projects for the Great Wall broadband, Founder and other broadband
10. ATL Projects in Shandong
packaging :
wooden roll add covering panel or according to customer's advice
trade terms:
FOB , CIF, CNF etc
remark
pls note that this price is 40GP FOB Qingdao full container load price , pls contact us for less than container load price
1.Are you a factory or trade company?
We are TOP 10 cable manufacturer in China, and we have legal import-export operation right.
2.Where is your location ? How can I visit there ?
Our factory is located in Wendeng District, Weihai City, Shandong Province , China.
We warmly welcome you to book a factory tour to visit us when you are free.
3.What kind of material do you use?
High quality PE, PVC, LSZH etc.
4.What is your after-sale service?
2 years warranty and professional technical persons to deal with your problems.
5.Do you provide any sample?
Yes, we provide samples for your reference, your feedback will be highly appreciated.
Free sample is available and can be sent within 3 working days once confirmed.
6.Could I order a small quantity for the first stage ?
Yes, we accept small order.
7.How many years is fiber cable's working time?
25 years.
8.How do you arrange OEM, ODM?
You can send us your design and drawing, and we welcome you to visit us for authorization and incumbency discussion.
9.How can I pay my purchase?
For bulk exports, we choose sea transportation,
for small order and sample, we choose DHL and UPC.
We accept payment by L/C, T/T, D/P, Western Union, Money Gram,Paypal and credit card.
10.Do you have distributors in any other countries ?
For overseas market, we sell our products to customers directly, and factory price is offered for you.
11.What's your international certificate?
CE,ROHS,SGS.
12.Do you have certificate for raw material ?
We build long-term friendly relationship with qualified ROHS raw material suppliers.
13.What's your delivery time?
Within 7 working days, our annual export volume is 200,000 km cables.
14.Bank information
We have 4 beneficiary banks
AGRICULTURAL BANK OF CHINA
INDUSTRIAL AND COMMERCIAL BANK OF CHINA
CHINA CITIC BANK
BANK OF CHINA
Our intermediary bank is JPMORGAN CHASE BANK
Any inquiry to ask you to pay on any other account is illegal.
