Aluminum tape armoured GYTA fiber optic cable for underground and duct

FOB Reference Price:Get Latest Price
$0.20 - $0.50 / Meters | 2000 Meter/Meters (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
Hongan
Model Number:
GYTA
Number of Conductors:
≥ 10
Type:
Coaxial
Color:
black
core number:
12
application:
duct,underground,aerial
certification:
CE,RoHS,TLC,ISO
sheath:
PE
Packing:
Wooden Drum
Shipping Port:
Qingdao Port
Supply Ability
Supply Ability:
10000000 Kiloampere/Kiloamperes per Year
Packaging & Delivery
Packaging Details
Wooden Drum
Port
Qingdao
Video Description
Product Description

             Aluminum Tape Armoured GYTA Fiber Optic Cable for Undergroud and Duct

This kind of cable is suitable for duct,  underground and aerial application.It is loose tube stranding structure with single PE sheath。 The aluminum tape and loose tube material guarantee the water-blocking and moisture-resistant performance.

Item
Parameter
Fiber-G652D
Attenuation Coefficient
1310nm
dB/km
≤0.4
1550nm
dB/km
≤0.3
Outer jacket
Material
MDPE
Color
Black
Min. bending radius
Static
10 times cable diameter
Dynamic
20 times cable diameter
Repeating bending
Load:150N;number of cycles:30 No obvious addition attention, no fiber break and no cable damage.
10 times cable diameter
Tensile performance
Short term
1500N The addition attention≤0.1dB,fiber strain ≤0.15%
Crush
Short term
1000N/100mm The addition attention≤0.1dB
Torsion
Load:150N; number of cycles:10; twist angle:±180° No obvious addition attention, no fiber break and no cable damage.
Impact
Impact energy:450g×1m; radius of hammer head:12.5mm; number of impact: 5 No obvious addition attention, no fiber break and no cable damage.
Packing & Delivery
Production Line
Certificates
Company Profile
Exhibition Show
FAQ

1. Are you the real factory?

Yes,our factory, locates in Shandong Province, with more than 30 years experience,near to Qingdao Port. Welcome to visit.

2. What is your fiber brand?

Our fiber brand is Weixin, and this fiber company is owned by Hongan ourselves.

3.What is your main products?

Our main products are outdoor and indoor fiber optic cable, FTTx cable, network cable and telephone cable.

4.What is your payment term?

30% in advance, 70% before delivery.
